Technical parameters
1 Voltage : AC100-240V, 50/60Hz
(2) Lamp : Philips 330W 15R
3 Optical Device: three lens lens group zoom 0 ° -5 °,
Electronic Focus
4 -channel mode : 20 international standard DMX512 Channel
5 Horizontal scan : 540 ° 16Bit ( accurate scanning )
Vertical scan : 280 ° 16Bit ( accurate scanning )
6 Color wheel: 9 colors + white , rainbow effect with bi-directional rotation
Gobo wheel : 17 gobos + white , patterned pattern jitter and arbitrary positioning function
7 Strobe: double guillotine strobe frequency up to 13 times per second , and can select a random strobe and
Strobe pulse
8 Dimming: 0% -100% linear dimming
9 atomization : 0% -100% linear atomization
10 Panel Display: LCD LCD
11 Strobe :0 -13 times / sec . Band random strobe
12 prism and the prism rotation : Rotating 3 facet prism , can be bi-directional rotation . Macro with 16 prism effect
13 Soft Effect : You can adjust the angle soft spot
14 Aperture : 5% to 100% , with an aperture effect
15 Focus: linear electron focusing
16 Dimming 0-100 % linearly adjustable , light projection range: X to 540 degrees , Y to 270 degrees
17 can automatically correct positioning, beam angle of 5 degrees to 27 degrees
18 Strobe: two-piece Strobe ( 0.5-9 times / sec. )
19 Motor Quantity: Total 16 ultra-quiet motors, two -phase motor , 16BIT driver
20 Other Functions : Remote control lamp switch function , display lamps, lamp usage time
21 Appearance : high temperature molded plastic + alloy
22 Protection Level : IP20, NW : 18.2KG
